Transcend Japan TS256GMTE470A 256GB M.2-2242 PCIe Gen3x4 NVMe/Self-Encrypting Drive (SED) M Key BiCS5 3D TLC NAND Heavy Duty (TBW: 240TB)

■Products purchased outside of Amazon.co.jp are not covered under the Japanese Japanese warranty

■Transcend MTE470A M.2 SSD is a self-encryption drive (SED)

Use hardware based AES-256 to encrypt data or limit access to specific LBAs

112 layers of 3D NAND flash and PCIe Gen 3 x4 interface to provide high speed performance

30µ" thick gold terminals, corner bonds and sulfide resistant tip resistors ensure reliability and rigorously tested to operate stable in temperatures from -20°C to 75°C The compact form factor of the M.2 2242 is ideal for small PC and POS applications

■Product Specifications Form Factor = M.2 2242-S2-M (one-sided mount) Bus Interface = NVMe PCIe Gen3x4 (M key) Size=42mm x 22mm x 2.23mm Built-in NAND Flash=112 layers 3D TLC NAND flash Capacity = 256/512GB/1TB

Maximum Read/Write Speed = Reading: 2,000 MB/s (IOPS: 102K), Write: 1,700 MB/s (IOPS: 275K) TBW:256GB=240TB, 512GB=406TB, 1TB=900TB Operating voltage: 3.3V±5% Operating Environment Temperature: -4°F to 155°F (-20°C to 75°C)

Storage Temperature: -55°C to 75°C Humidity: 5%-95%

Vibration resistant (when operating) 20G (maximum amplitation), 7 Hz - 2,000 Hz (frequency) Shock Resistant: Acceleration: 1500G, 0.5ms, 3 axis Power Consumption: Operating = 2.9W, Idel= 0.53W, MTBF: 3,000,000 hours
