KONYEAD 3006 PCIe 4.0 x8 to 4-Port NVMe M.2 2280 SSD Expansion Card, Half-Height Adapter with Aluminum Heatsink, Dual Turbo Fans, Temperature Control, Up to 32TB (4x8TB), Low Profile Bracket Included

[Quad NVMe SSD Expansion] PCIe 4.0 x8 interface fan-out to 4 independent PCIe 4.0 x4 NVMe M.2 slots, each supporting 2280 form factor SSDs up to 8TB, with a total capacity of 32TB

Backward compatible with PCIe 3.0

Based on IX8024 controller IC for reliable high-speed performance

Ideal for upgrading storage in compact systems and servers

[Dual-Sided Mounting Design] Install up to 4 NVMe SSDs simultaneously — 2 SSDs on the front side and 2 SSDs on the back side of the card

Each SSD slot features an independent green LED indicator that flashes during read/write operations, giving you real-time activity monitoring at a glance

[Advanced Thermal Management] Premium aluminum alloy enclosure with sandblasted anodized finish for efficient heat dissipation

Includes 4 silicone thermal pads to transfer heat from SSDs to the metal chassis

Dual turbo fans with intelligent temperature control — fans remain off below 40°C, and auto-adjust speed between 40°C–60°C for silent, efficient cooling

[Low Profile & Versatile Fit] Compact half-height (low-profile) design measuring 176 x 82 x 25 mm and weighing only 253g, perfect for small form factor (SFF) chassis and compact workstations

A full-height bracket is also included in the package, allowing easy swap to fit standard ATX cases

Plug and play — no driver installation required

[OS Compatibility & RAID Support]Supports Windows operating systems out of the box (other OS may require user testing)

Note: Hardware RAID is not supported, but the card fully supports software RAID functions built into your operating system, allowing you to configure RAID 0/1/10/JBOD through your OS for flexible storage solutions
